1.  Features



1.  More reasonable structure and higher strength steel as a whole.

2.  Used  together with CD1 and MD1 model electric hoist as a complete set.

3). It ’ s a light duty crane with the capacity of 1 ton to 20 tons. The span is 7.5-38.5m. Working grade is A3-A5. Working temperature is -25-40 ° C.

4.  Two operational types: ground or operational room which has open type and closed type. It can be adjusted according to the practical situation.



Notice:

It is forbidden to used in the combustible, explosive or corrosive  environment .



  2. Main Specifications





The product name	Electric single girder overhead crane
Specifications	LD 1-20t
Span	7.5-38.5m
Max. lifting height	22m
Hoisting speed	0.8-5m/min
Crab traveling speed	20m/min
Gantry traveling speed	20-30m/min
Applicable  environment : this product is widely used in factory, warehouse,  yard for loading and unloading handing .







3.packaging & shipping



1. Packing: Wooden case for electric parts and high quality plastic cloth for others.

2.Delivery time: 35 days. The detail time can be adjusted according to the  practical order.



  4.Our Services





Attention



In order to offer you most suitable design and best solution, please confirm the following information when you send inquiry:



1-      Lifting capacity?



2-      Single girder bridge crane or double girder bridge crane or other kinds?



3-      Lifting height?



4-      The span of the main girder?



5-      Power supply?



Thanks for your kindly information, we will support you the suitable quotation according to the above information.





 5.Company Information





Shandong Deluke Crane co., LTD is a professional manufacturer for crane in China from 2009. It is mainly engaged in European standard single and double beam bridge crane and gantry crane’s design, manufacturing, and installation work.



DLK is a full subsidiary of Guangming Hoisting Machinery Group. It is a high-tech enterprise cooperating with FITOP Machinery co., LTD, and also is a supporting institution of Shandong Hoisting Machinery Automation Engineering Technology Research Center.



DLK products derived from international advanced German technology, the main product is advanced European standard hoisting machinery, based on energy conservation and environmental protection, lightweight, low failure, convenient operation, easy maintenance, creating economic practical value and complete services.



We promise that our reasonable price and the high quality will satisfy you perfectly.
